Tekonsha's 303700 is a plug-in brake controller harness cut for 2007-2025 BMW X5. It connects a Tekonsha brake controller to the vehicle's factory brake-control port, so the controller wires in without splicing into the vehicle loom. Rated at 30A and 12V.
- Vehicle-specific plug-in fit
- No splicing into the factory harness
- Square connector (male)
- 2 connector(s)
- 4 terminals
- Rated to 30A
- Wire colours: Black, Red, Blue White
- Limited 1 Year Warranty
Specifications
| Part number | 303700 |
|---|---|
| Type | Brake Controller Harness |
| Fit | Specific Fit |
| Amperage | 30A |
| Voltage | 12V |
| Connector shape | Square |
| Connector gender | Male |
| Connectors | 2 |
| Terminals | 4 |
| Terminal type | Blade |
| Wire colours | Black, Red, Blue White |
| Shipping dimensions | 8" x 3" x 11" (Shipping) |
| Weight | 2.1 lb |
| UPC | 016118166989 |
| Warranty | Limited 1 Year Warranty |
| Fits | 2007-2025 BMW X5 |
