Buyers Products Single and Dual Axis Air Control Valves are available in a variety of handle configurations: Proportional, Feathering, and Stackable. Used in many applications, such as hook lift/cable lift hoists, dump bodies, and snow plows.
Single or dual axis options available with varying handle configurations and knob styles. An LED light or push button on/off switch on top of the handle offers additional functionality.
- Air control valve available in a variety of handle configurations and includes hardware to stack.
- Capable of many applications including operation of hook lift/cable lift hoists, dump bodies, snow plows, cranes, wreckers, and more when paired with air-controlled hydraulic system.
- Handle movement in either direction allows controlled proportional feathering pressure output to work ports 'A' or 'B' respectively.
- Available with LED light or push button on/off switch on top of handle for additional functionality.
Specifications
- Depth (in.): 4.7 in.
- Feathering: Yes
- Height (in.): 10 in.
- Neutral Lock Out (y/n): Yes
- Number of Detents: 1
- Port Type: 1/8 NPT female
- Spring to Neutral / Deadman Control (y/n): Yes
- Valve Action: Double Acting
- Valve Actuation: Single axis lever control, neutral locking straight handle with lift to release collar and LED light in top of knob
- Valve Primary Application: Hoist Control - Stackable
- Width (in.): 1.4 in.
