SALTDOGG® 2.5-5.5 CUBIC YARD HYDRAULIC AUGER SPREADER

14709F523211 - SALTDOGG® 2.5-5.5 CUBIC YARD HYDRAULIC AUGER SPREADER

• Designed for dump bodies and flatbeds with a minimum 15,000 GVW.
• Durable 304 stainless steel hopper for superior corrosion resistance.
• Powered by two independent hydraulic motors for auger and spinner.
• Spreads bulk salt or a 50/50 sand/salt mix.
• Hydraulic controls sold separately.
• 18 in. poly spinner with six fins broadcasts up to 30 ft.
• 5-1/4 inch variable pitch auger with a 304 stainless steel adjustable inverted V for optimum corrosion resistance and to improve flow and reduce stress on the drive line.
• 12 inch adjustable height swing-away spinner chute has three adjustable internal baffles and quick detach pins for convenient bulk unload, easy servicing, and access to towing.
• Four hinged top screens with 1/4 inch diameter bars included.
• Made in the U.S.A.

Buyers Products SaltDogg 2.5-5.5 Cubic Yard Hydraulic Auger Spreader gives contractors and municipalities a heavy duty, durable spreader that is powered by a central hydraulic system (not included). The hoppers are designed for dump bodies and flatbeds with a minimum 13,000 lb GVW (gross vehicle weight) chassis; depending on size of spreader. It works with bulk salt, bulk sand, or a 50/50 salt/sand mix. The highly corrosion-resistant 304 stainless steel hopper features a fully-welded frame. It comes equipped with two hinged top screens with 1/4 in bars. The 5-1/4 inch variable-pitch auger is covered by an inverted V to reduce stress on the drive line and improve material flow. The conveyor chain is driven direct-drive hydraulic motor. The spinner is powered by a direct mount hydraulic motor. An 18 in. poly spinner casts material 2 ft to 30 ft. The spreader is available with a regular or extended chute. Two adjustable baffles allow you to cater the spread pattern to your use. The chute and spinner assembly flips up or detaches completely, tool-free, for convenient bulk unload, easy servicing, and access to towing. Hydraulic spreader controls are sold separately. A variety of options are available, including manual hydraulic, manual with load sensing, and electric over hydraulic, available with or without GPS. Pictured with optional spreader stand (3037291) sold separately.

• Capacity - 5.00 yd¬≥
• Chute Primary Material - 304 Stainless Steel
• ChuteStandardAdjustableExtended - Adjustable Height
• Controller Type - Not Included
• Feed Mechanism - Full Length Auger
• Feed Mechanism - 25 1/4in. Variable Pitch Auger
• Gearbox Ratio - Direct
• Hopper Material - 304 Stainless Steel
• Number Of Motors - 2
• Overall Length - 128.00 "
• Overall Width (At Top) - 70.00 "
• Spinner Diameter - 18.00 "
• Spinner Material - Polyurethane
• Spreading Width Range - 2 To 40 '
• Top Screen - Yes
• Trough Material - 304 Stainless Steel
• Vibrator Included? - No
• Works With Bagged #1 Rock Salt - Yes
• Works With Bulk Salt - Yes
• Works With Bulk Sand - No
• Works With Salt / Sand Mix - Yes
• Drive Type - Hydraulic
• Hopper Length (In.) - 108.00 "
• Hopper Width (In.) - 70.00 "
• Overall Height (In.) - 52.00 "
